Product Quick Specifications:
Type of machines that are applicable:
MIG & TIG Torches
Product Full Specifications:
S P E C I F I C A T I O N
|
Model
|
WCS 302
|
|
AVAILABLE VOLTAGE
|
230VAC
|
|
RATED FREQUENCY
|
50/60Hz
|
|
POWER RATING
|
50Hz
|
0.22kW
|
|
60Hz
|
0.30kW
|
|
CURRENT CONSUMPTION
|
50Hz
|
1.10A
|
|
60Hz
|
1.35A
|
|
IMMERSION PUMP
|
Qmax
|
PUMP CAPACITY
|
50Hz
|
9L/min
|
|
60Hz
|
10L/min
|
|
Hmax
|
PUMP PRESSURE
|
50Hz
|
3.3BAR
|
|
50Hz
|
4.4BAR
|
|
PUMP DISCHARGE
|
33M
|
|
COOLING CAPACITY
|
750 - 1000W
|
|
HEAT EXCHANGER
|
3row
|
|
TANK CAPACITY
|
8L
|
|
CONNECTOR SIZE
|
In
|
5/8� X 18G Inch
|
|
Out
|
5/8� X 18G Inch
|
|
DIMENSIONS (W x H x L)
|
315 x 319 x 522mm
|
|
NET WEIGHT
|
17.3kg
|
|
*Please note that the duty cycle value may varies according to room temperature.
|
